Upc Plug Plastic Model 1550nm Low PDL Fiber Attenuator Lc

Name: Upc Plug Plastic Model 1550nm Low PDL Fiber Attenuator Lc
Brand: SUNET/OEM
Price: 1.5 USD

China Upc Plug Plastic Model 1550nm Low PDL Fiber Attenuator Lc wholesale

Brand Name : SUNET/OEM

Model Number : SNT-FOA

Certification : ISO9001/ISO14001

Place of Origin : Qingdao,China

MOQ : 1 Piece

Price : USD 1.5-5

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 1000000 pcs per week

Delivery Time : 5-8 work days

Packaging Details : 1 pc in one bag

Product name : Fiber Attenuator

Type : Male - Female

Connector type : LC/SC/FC/ST

Attenuation range : 1~30dB or customized

Wavelength : 1260 to 1650nm, 1310/1550nm

Material : Metal

Fiber type : Single mode

Application : CATV

Contact Now

Lc Upc Plug Type Plastic Model Fiber Optic Attenuator

Attenuator Description

Fiber Optic Attenuator is one kind of optical passive device which is used to debug the performance of the optical power in the optical communication system,debugging fiber optic instrument calibration correction, optical signal attenuation. And used for the attenuation of the input optical power, avoid optical receiver distortion due to input optical power powerful. The fixed fiber optic attenuator can achieve the dual function of adapter and attenuator.

Attenuator Feature

1. Low back reflection and Low PDL

2. High precision attenuation value

3. Precision control of attenuation range

4. Wide attenuation range

5. Precision ceramic ferrule

6. FC,SC,ST,LC...optional

7. Plastic or metal housing material

8. Comply with Telcodia GR-310-CORE.

Attenuator Application

1. Fiber optical telecommunication system

2. Fiber optical CATV

3. Fiber optical sensor

4. Testing equipment

Attenuator Specification

Item	Parameter
Model	Fixed Type
Operating Wavelength	SM:1310/1550nm
Attenuation Range	1~30dB
Return Loss	UPC: ≥55dB APC: ≥60dB
Attenuation Tolerance	≤+/-0.5(1-10dB) or ≤+/-1.0(11-30dB)
Maximum Optical Input Power	1000mW
Polarization Dependent Loss	≤0.1dB
Working Temperature	-40°C~+75°C
Storage Temperature	-40°C~+ 85°C
Humidity	95%RH
